| MODEL | Unit of Measure | Working Range | A | B | C | SHIPPING WEIGHT | MACHINE WEIGHT | PACKAGE SIZE | ||
| CS6 | Std.-in. | 2°-6” | 7.3 | 20.2 | 7.6 | 67.5kg | 41.5kg | 28.3*25.2*11.4 | ||
| Metric-mm | 50-168 | 185 | 512 | 192 | 148.5lbs | 91.3lbs | 720*640*290 | |||
| CS8 | Std,-in | 2′-8” | 9.3 | 22.2 | 7.6 | 75.5kg | 42.5kg | 27.9*26.8*11.4 | ||
| Metric -mm | 50-230 | 236 | 564 | 192 | 166.1lbs | 93.5lbs | 710*680*290 | |||
| CS10 | Std,.in | 4″-10* | 11.1 | 24.1 | 7.6 | 79.5kg | 44.5kg | 27.9*26.9*11.1 | ||
| Metric -mm | 114-275 | 283 | 612 | 192 | 174.9lbs | 97.9lbs | 710*685*280 | |||
| CS12 | Std-in | 6*-12* | 13.1 | 26.2 | 7.6 | 88kg | 53kg | 31.5*28.9*10.8 | ||
| Metric -mm | 168-325 | 334 | 665 | 192 | 193.6lbg | 116.6lbs | 800*735*275 | |||
| CS14 | Std.-im | 8″.14* | 15.2 | 28.3 | 7.6 | 94kg | 56kg | 33.1*11.1*11.2 | ||
| Metric-mm | 219-377 | 386 | 719 | 192 | 206.8lbs | 123.2lbs | 840*280*285 | |||
| CS16 | Std.-in | 10″-16” | 17.2 | 30.6 | 7.7 | 100kg | 60kg | 35.1*28.1*10.8 | ||
| Metric-mm | 273-426 | 438 | 776 | 195 | 220lbs | 132lbs | 890*715*275 | |||
| CS18 | Std,-in | 12-18* | 18.5 | 31.8 | 7.7 | 106.5kg | 65.5kg | 34.6*29.1*11.4 | ||
| Metric -mm | 300-457 | 469 | 807 | 195 | 234.3lbs | 1441lbs | 880*740*290 | |||
| CS20 | Std-in | 14″-20° | 20.4 | 33.9 | 7.7 | 122kg | 77kg | 38.9*32.3*12.6 | ||
| Metric-mm | 355-508 | 519 | 862 | 195 | 268.4lbs | 169.4lbs | 990*820*320 | |||
| CS22 | std-in. | 16″-22 | 22.4 | 35.8 | 7.7 | 127kg | 79kg | 38.9*36.2*13.4 | ||
| Metric-mm | 400-560 | 570 | 910 | 195 | 279.lbs | 1732.8lbs | 990*920*340 | |||
| CS24 | Sld..in | 18°-24* | 24.3 | 37.8 | 7.7 | 134kg | 85kg | 42.5*35.4*13.8 | ||
| metrie-mm | 457-610 | 618 | 960 | 195 | 294.8lbs | 187lbs | 1080*900*350 | |||
| CS26 | Std,-in | 20″-26* | 26.4 | 40.2 | 7.7 | 150kg | 96kg | 38.9*33.9*13.4 | ||
| Metric -mm | 508-660 | 670 | 1020 | 195 | 330lbs | 211.2lbs | 990*990*340 | |||
| CS28 | Std.-in | 22”-28” | 28.3 | 42.7 | 7.8 | 169kg | 114kg | 40.5*40.5*13.4 | ||
| Metric -mm | 550-715 | 719 | 1084 | 198 | 371.8lbs | 250.8lbs | 1030*1030*340 | |||
| CS30 | Std,.in | 24″-30 | 30.3 | 44.6 | 7.8 | 172kg | 116kg | 42.9*42.9*13.4 | ||
| Metric -mm | 600-762 | 770 | 1134 | 198 | 378.4lbs | 255.2lbs | 1090*1090*340 | |||
| CS32 | Std,-in | 26″-32 | 32.7 | 47.0 | 8.1 | 181.5kg | 120.5kg | 44.8*44.8*13.4 | ||
| Metric -mm | 660-813 | 830 | 1194 | 207 | 399.3lbs | 265.1lbs | 1140*1140*340 | |||
| CS36 | Std-in | 30-36° | 36.4 | 51.0 | 8 | 209.5kg | 144.5kg | 49.2*492*14.9 | ||
| Metic -mm | 762-914 | 924 | 1296 | 214 | 460.9lbs | 317.9lbs | 1250*1250*380 | |||
| CS42 | Std.-in | 36″-42 | 42.4 | 57.8 | 8.5 | 281.5kg | 197.5kg | 56.3*31.9*14.9*2 | ||
| Metric -mm | 914-1066 | 1077 | 1468 | 216 | 619.3Ibs | 434.51b8 | 1430*810*380*2 | |||
| CS48 | Std.-in | 42*-48* | 49.1 | 64.8 | 8.5 | 347kg | 244kg | 64.5*35.8*14.9*2 | ||
| Metric-mm | 1066-1230 | 1248 | 1646 | 216 | 763.4lbs | 536.8lbs | 1640*910*380 *2 | |||
